Zurn Wilkins 1260XL Copper Piston Water Hammer Arrestor
Zurn Wilkins 1260XL Copper Piston Water Hammer Arrestor protects residential, commercial and industrial water lines against banging and over-pressure during surges following quick valve closure.
Features & Benefits:
- Reduces pipe banging caused by water hammer
- All copper and brass external construction
- Air chamber is permanently sealed
- Low-lead law compliant
- Replaces Zurn Wilkins 1250XL
Ideal for use where Lead-Free* fittings are required. Designed to protect residential, commercial and industrial water lines during pressure surges following quick valve closure. This excessive pressure surge is absorbed by the pre-charged cushion of air permanently sealed within the water hammer arrester. The water hammer arrester may be installed within a stud bay without the need for an access panel.
- ASSE® Listed 1010
- ANSI A112.26.1
- Certified to NSF/ANSI 372* by IAPMO R&T *(0.25% MAX. WEIGHTED AVERAGE LEAD CONTENT)
- Body: Copper Tube (seamless, Type “L”)
- Tailpiece: Low Lead Brass
- Piston: Acetal, Polycarbonate or Low Lead Brass O-rings
- EPDM: Solder Lead Free
- Temperature range -40°F to 212°F
- End connections Threaded ANSI/ASME B1.20.1
Maximum transient pressure surge, with arrester properly sized and placed in the water supply system, will not rise above 150 psi following quick valve closure. Maximum static pressure: 200 psi. For best performance, static line pressure should not exceed 85 psi; contact the factory for proper sizing if static pressure is greater. Max spike pressure 400 psi.
The Water Hammer Arrester shall be certified to NSF/ANSI 372, consist of a copper body with a low lead brass hexagonal male pipe threaded inlet, an acetal, polycarbonate or low lead brass piston, EPDM o-rings and lead free solder. The device shall be pre-charged and sealed at the factory. The Water Hammer Arrester shall be a ZURN WILKINS Model 1260XL.
Zurn Wilkins 1260XL Copper Piston Water Hammer Arrestor Specification Submittal: Click Here.
Zurn Wilkins 1260XL Copper Piston Water Hammer Arrestor Installation Instructions: Click Here.
Zurn Wilkins 1260XL Copper Piston Water Hammer Arrestor BIM Model: Click Here.
Zurn Wilkins 1260XL Copper Piston Water Hammer Arrestor Irrigation Water Hammer Arrestor Sizing: Click Here.
Mitigating Water Hammer Learning Video:
Zurn Wilkins 1260XL Lead-Free Copper Piston Water Hammer Arrestor Crosses:
- Ancon / Watts LF15M2, LF152M2-A, LF152M2-B, LF152M2-C, LF152M2-D, LF152M2-E, LF152M2-F
- Mifab CLS.
- 1260XL-A Replaces 1250XL-A
- 1260XL-B Replaces 1250XL-B
- 1260XL-C Replaces 1250XL-C
- 1260XL-D Replaces 1250XL-D
- 1260XL-E Replaces 1250XL-E
- 1260XL-F Replaces 1250XL-F
